These are complete, ready to use units including pump. The pressurized system makes the finest, uniform and dense Micro-Nano Bubbles.

Our standard models are made for clean water and ambient air to produce Micro-Nano Bubbles.  Chemical resistance version is available upon request.  Other custom OEM design is also available.

AS-MK III

Brochure link / Movie link

Large scale generators for various applications

SMX-155  Brochure link

SMX-374  Brochure link

SMX-554  Brochure link

YJ-Series Micro-Bubble Generating Nozzles

Introduction

• It has been a problem to scale up MNB devoices for large volume applications due to their limited air supply capability.
• YJ-Nozzle solved the problem. Now you can supply MNB with higher Air/Water ratio.
• YJ-Nozzle is simple to use as similar to ejectors and venturi tubes and fit easily to various type of pumps for design flexibility.

Advantages

The highest power efficiency MNB device

• Air supply volume (adjustable) is up to 33% of water flow.
  This is far larger than other MNB devices (2-10%).

• Large orifice size enable pump to work without pressure loss.

• Thanks to large orifice size (the smallest one even has 9 mm diameter), you don’t have to worry about clogging. Maintenance free.

• Easy to use. Just connect it to pump.
  Air is supplied automatically through air-inlet pipe.

• Water comes out as “Jet flow” which spread MNB to entire volume in a hurry.

• Generation of OH radicals further enhance the performance.

YJ-Nozzle with submersible pump

TR-6242 Micro-Bubble Nozzle

"Tornado" Micro-Bubble nozzle TR6242 is an original "Swirling" type Micro-Bubble nozzle. It is an economical solution for various small to medium volume applications.

Pump requirement: Minimum pressure of 0.04 Mpa at 30-60 l/m water flow rate

TR6242 Connecting Diagram

.

BT-50 Series Micro-Bubble Nozzle

BT series nozzles are very well designed, compact, low power usage Micro-Nano Bubble generating device. Liquid Thin Film (LTF) devices are based on very unique concept to transfer air in and out of water.

BT-50 Micro-Nano Bubble Nozzle

BT-50 is also “Swirling” type Micro-Nano Bubble device. You can introduce air from pump or through air hose. The design structure minimizes the friction thus stable high speed swirling motion create uniform Micro-Nano bubbles. This is used as very handy experimental tool as well as efficient aeration for hydroponics, aquaculture, Bio-filter and flotation applications.

Video link

S.BT-50 Micro-Nano Bubble Nozzle with MNB400 pressure chamber

This combination is “Pressurize” method of Micro-Nano Bubble generation. This type makes very thick and uniform Micro-Nano Bubbles (milky appearance). The application include dissolving special gasses (like Ozone, Oxygen, CO2, Hydrogen etc. ) and flotation, making emulsion etc.

Video link

.

Liquid Thin Film Devices

F.BT-50 Liquid Thin Film/Micro-Bubble Nozzle

This is a combination of Liquid Thin Film and Micro-Nano Bubbles. This type is very popular for aquaculture application.

F.BT-50W Liquid Thin Film Nozzle

Low power LTF device for effective gas transfer in and out of water.

AWA200 Liquid Thin Film device

This Liquid Thin Film concept device is developed for wastewater treatment.

This multi-layer device efficiently transfers unwanted gasses out from wastewater to make rooms for wanted oxygen gas.
